Multifunction KP-45X with 65YC

Length : 628 mm

Weight : 9.6 kgs (w/o battery)


■ Specifications :
Drive unit : 18V DC motor
Charger (GS/CE) :
Input voltage : 110V single phase AC
Input voltage : 230V single phase AC
Input frequency : 50~60Hz
Input current : 21.75 VA
Reservoir capacity : 175 cc


■ Cutting Capacity :

Max. pressure : 700 bar

Max. output : 14.01 tons / 124.6 kN

Ram stroke : 45 mm

Cu strands : 60 mm

Al strands : 60 mm

CCP cable : 65 mm

Underground cable : 65 mm

(Except armoured cable)

■ 65YC

    (Cable Cutter Head Adapter)

Cutting capacity :

Cu strands : 60 mm

Al strands : 60 mm

CCP cable : 65 mm

Underground cable : 65 mm

(Except armoured cable)

※Cutting of piano wire is prohibited.
