Detail
Height : 327 mm
Weight : 4.6 kgs (w/o battery)
■ Specifications :
Drive unit : 18V DC motor
Charger (GS/CE) :
Input voltage : 110V single phase AC
Input voltage : 230V single phase AC
Input frequency : 50~60Hz
Input current : 21.75 VA
Reservoir capacity : 120 cc
■ Crimp capacity :
Max pressure : 550 bar
Max compression : 300 mm²
Crimping force : 6.90 tons / 61.4 kN
※Dies sold separately(T16/25/35/50/70/95/120/150/185/240/300)
