Detail
Length : 506 mm
Weight : 8.3 kgs (w/o battery)
■ Specifications :
Drive unit : 18V DC motor
Charger (GS/CE) :
Input voltage : 110V single phase AC
Input voltage : 230V single phase AC
Input frequency : 50~60Hz
Input current : 21.75VA
Reservoir capacity : 175 cc
■ Crimp capacity :
Jaw opening : 50 mm (45 mm ADP-15THE)
Max pressure : 700 bar
Crimping force : 15.2 tons / 134.7 kN
※Dies sold separately (15THE-CU400 / 500 / 630)
■ ADP-15THE :
This adapter is designed for hydraulic compression head to interchange with die sets for other 12-ton tools ( up to 400 mm² )
